WallBox-MSE-EU-02A0-22
• Easy to install
• OCPP1.6J/2.0, Tuya platform
• APP manage your wall-box anywhere through WIFl and 4G.
• Bluetooth local control without network
• IP65
• RS485 meter or CT-Clamp toachieve dynamic load balancing
• OCPP1.6J/2.0, Tuya platform
• APP manage your wall-box anywhere through WIFl and 4G.
• Bluetooth local control without network
• IP65
• RS485 meter or CT-Clamp toachieve dynamic load balancing
| Input | ||||
| Wiring Scheme | 3P+N+PE | |||
| Rated Voltage [Vac] | 400±10% | |||
| Maximum Current [A] | 32 | |||
| Frequency[Hz] | 50/60 | |||
| Output | ||||
| Voltage[Vac] | 230±10% | |||
| Maximum Current [A] | 32 | |||
| Rated Power[kW] | 22(MAX) | |||
| Specifcation | ||||
| FIRE rating | UL94-V0 | |||
| Ingress Protection | IP65 | |||
| Resistance Voltage [V] | Between L.N and PE, 2000AC | |||
| Insulation resistance [MΩ] | >1000MΩ (DC500V) | |||
| Cable specification | 3*6mm²+1*0.5mm² | |||
| Contact resistance [Ω] | <0.5Ω | |||
| Confguration | ||||
| Output Connercter(tocar) | Type2 Socket | |||
| Material | PC/+ASA | |||
| Charging Mode | Plug&Play/RFID NFC/APP | |||
| Safety | ||||
| Protection | Over current protection, Residual current protection.Ground protection, Over/Under voltage protection, Over/Under frequency protection, Over temperature protection |
|||
| Leakage Current Protection | AC30mA+DC6mA | |||
| Surge Protection | 4kV@2500A | |||
| Generation Information | ||||
| Installation | Wall-mount/Post-mount | |||
| Operation Temperature[℃] | -30℃~50℃ | |||
| Storage temperature [℃] | -35℃~55℃ | |||
| Operating Humidity[%] | 5~95, No condensation | |||
| Operation Altitude[m] | <2000m | |||
| Warranty [year] | 2 year | |||
| Product Dimension(W*H*D)[mm] | 375*199*118mm | |||
| Package Dimentions [mm] | 540*400*250mm | |||
| Weight [kg] | 5.9 | |||
| Certification | CE, CB, TUV | |||
| Certification Standard | EN/IEC 61851-1:2019,EN/IEC 61851-21-2:2021 | |||
